Product Description
USB UHF RFID Desktop Reader with Gen 2 for Write tag uhf rfid reader usb
Product Parameter | Parameter Description |
Model | UHF105 uhf reader writer |
Interface | USB 1.1, cable length of 1 meter |
Operation Mode | Fixed Frequency or FHSS or Software Programmable |
RF Power supply | DC 5V / 90 mA |
Built- in Antenna Type | Built-in small round polarization Antenna |
Peripheral Equipment | LED, Buzzer |
Output power | 0~ 13 dBm ( Software adjustable) |
Protocol | ISO18000-6C & EPCglobal Class I Gen 2 |
Anti-collision | Tag processing algorithm, multiple tags operation allowed |
Software | Demo software, SDK, Dull |
Product Advantages
–Self-intellectual property;
–Support UHF EPC Gen2(ISO18000-6C),ISO18000-6B protocol tags;
–Advanced tag processing algorithm, high identification rate;
–Built-in antenna with effective distance up to 180cm;
–Low power dissipation design;
–Optional USB interface;
–Provide DLL and Demonstration Software Source code to facilitate further development;
–Provide Pocket PC/ PDA demo source code
Quality Warranty
– Warranty Service will be honored if the damage is not caused by human, we provides 1 years warranty for relative products.
Application
Step one : Connection reader with PC/laptop through usb interface
Step two: Open notepad or a word document, click mouse,
put card on the reader, the card number will output on the notepad or word document
